09 maintenance and servicing, Fuses – Volvo 2009 C70 User Manual
Page 230
09
230
55.
Not in use
56.
Volvo Navigation System
remote control module
(option), alarm siren control
module
10A
57.
On-board diagnostic
socket, brake light switch
15A
58.
Right high beam, auxiliary
lights relay
7.5A
59.
Left high beam
7.5A
60.
Heated driver's seat
(option)
15A
61.
Heated passenger's seat
(option)
15A
62.
Not in use
63.
Power window – rear pas-
senger's side
20A
64.
Volvo Navigation system
(option), lock indicator
lights in door panels
5A
65.
Audio system
5A
66.
Audio system control mod-
ule (ICM), climate system
10A
67.
Not in use
68.
Cruise control
5A
69.
Climate system, rain sensor
(option), BLIS button
(option)
5A
70.
Not in use
71.
Not in use
72.
Not in use
73.
Front ceiling lighting
5A
74.
Fuel pump relay
15A
75.
Not in use
76.
Not in use
77.
12-volt socket in trunk, aux-
iliary equipment control
module (AEM)
15A
78.
Not in use
79.
Back-up lights
5A
80.
Not in use
81.
Power window and door
lock – rear driver's side
82.
Power window – front pas-
senger's side door
25A
83.
Power window and door
lock – front driver's side
door
25A
84.
Power passenger's seat
25A
85.
Power driver's seat
25A
86.
Interior lighting relay, trunk
lighting, power seats
5A
