Draco (Cross) Repeater
24
2014-04-15
1
2
4
5
8
3
7
9
6
Pos: 46 /806-IHSE/zz_Layout/Seitenumbruch @ 8\mod_1348581820516_0.doc @ 69459 @ @ 1
Dual Media Conversion
1
Source (computer, CPU)
2
KVM Extender CPU Unit
3
Interconnect cable (Cat X)
4
(Cross) Repeater #1
5
Interconnect cable (fiber)
6
(Cross) Repeater #2
7
Interconnect cable (Cat X)
8
KVM Extender CON Unit
9
Console (monitor, keyboard, mouse)
