ENGLISH
16
OTHER FUNCTIONS
MULTI ROOM SELECTOR
The Multi Room Selector is a function which allows you to listen to the
same or a different source in a room other than the room in which the
AV9000 is located. To use this function, a multi room remote unit and
remote control signal receiver available from your Marantz dealer are
necessary. The operations possible with the multi room function are
explained briefly below. For details, refer to the instruction manual
supplied with the multi room remote control unit and receiver.
MULTI ROOM SELECTOR OPERATION
1. Press the MULTI D8 on page 2 at AMP MODE on the remote. The
unit enters multi room mode and the display indicates “SEL
SOURCE”. The “MULTI” indicator flashes for approx. 10
seconds. During this time, you can select the input source by
turning the
INPUT SELECTOR knob !9 or FUNCTION button .
on the remote.
2. After above, the display indicates “MULTI VOL” “VOLUME xx dB”
for approx. 5 seconds. During this time, you can set the volume
level for the multi room operation by volume knob or remote
cotrol. This will only set the volume in the other room.
MULTI ROOM SELECTOR OPERATION (USING THE MULTI
ROOM REMOTE CONTROL UNIT)
1. Press the MULTI D8 on page 2 at AMP MODE on the remote, the
POWER ON button, or select the desired source on multi room
remote control unit from the MULTI ROOM. Any of these
operations will put the AV9000 into multi room mode and “MULTI”
will light in the display.
2. Press the VOL.UP or VOL.DOWN button on the multi room
remote control unit to set the desired sound volume.
3. In multi room mode, the multi room remote control unit can be
used in the multi room to operate the following functions.
You can select a tuner preset channel and tuning up or down,
and direct selection. And you can control the CD player LD
player, DVD player and tape deck connected to the AV9000.
Caution:
Multi room mode can be selected when the AV9000 POWER
switch q is turned on.
If the main room is active (not standby mode), you cannot select a
radio band except the band being used in the main room. For
example; if the FM band is selected in the main room, you cannot
select the AM band in the multi room.
The operating procedure for this is the same as the Multi-room
operations using the remote unit.
TV AUTO ON/OFF FUNCTION
This function allows the component connected to the TV IN jack to
control the power (ON/OFF) to the AV9000.
AUTO POWER ON
1. Connect your TV TUNER (etc) to the TV IN terminal.
Be sure to connect the video input.
2. Turn OFF the power to the TV TUNER and the AV9000.
3. Turn ON the TV TUNER and tune in a receivable station.
4. When the station is received, the AV9000 turns ON and TV is
selected automatically.
AUTO POWER OFF
1. In the above situation, turn the TV TUNER OFF or select a channel
that does not contain any broadcast.
2. The power to the AV9000 switches to STANDBY after approx. 5
minutes.
Note:
AUTO POWER OFF is canceled if the INPUT SELECTOR knob !9
is set to a source other than TV. The function reactivates when TV
is selected again.
Caution:
Some TV broadcasts may cause the TV AUTO FUNCTION to be
turned ON. To set this function ON/OFF, refer to the SETUP MENU.
SETTING THE SLEEP TIMER (ONLY REMOTE
CONTROL UNIT)
Set the sleep timer while the power is turned on.
1. Turn the power ON and press the SLEEP button D5 on page 4 at
AMP mode.
“SLEEP” blinks on the display.
2. Press the SLEEP button D5 the number of times to set the
desired sleep time.
Each press of the
SLEEP button D5 changes the display in the
following order:
“SLEEP” stops blinking and lights steadily.
* While the sleep timer is activated, the remaining time can be
displayed for approx. 2 seconds by pressing the SLEEP
button D5.
* To cancel the sleep timer, press the SLEEP button D5 and
then press the C (CLEAR) button ⁄4.
10 20 30 40 50
OFF 90 80 70 60
