5-42 707096-005
iCON-XT Single Station Console Terminal User’s Manual
• Portrait – If enabled, prints in Portrait mode. If disabled, prints in Landscape
mode.
• Mod 5 17 CPI – If selected, printing automatically changes to 17 CPI (characters
per inch) if the application screen is Mod 5.
• Wide Paper – If enabled, allows printing of more than 80 characters per line. This
setting is generally used when Proprinter is selected as the Printer Type.
• LPR Setup
– LPR Printer Window – Select the defined printer that will receive 1451 print
jobs. Once selected, the Local Name, Remote Name, and Remote Address will be
displayed below the LPR Printer Window.
• Line Feed – Sends an immediate Line Feed to the selected printer.
• Form Feed – Sends an immediate Form Feed to the selected printer
About
From the main 1451 screen:
1. Click Setup.
2. Click About.
A dialogue box will appear displaying the version of the 1451 installed and the
copyright notice.
Macro Record/Playback
The 1451 macro function enables you to reduce the number of keystrokes required
for a frequently repeated entry such as a logon sequence. Unique keystroke
sequences can be stored for each of the 24 function keys on the keyboard. The
entered keystroke sequences are stored in nonvolatile memory, which means that
the data is retained even if the power is turned off.
Note: There is a 7000 key limit on the length of each macro.
