Board Layout
Chapter 3
Embedded and Industrial Computing
Internal Connectors and Jumpers
The following picture highlights the location of internal
connectors and jumpers. Refer to the table 3.1 Connector
List for more details.
J4
SW5
LEB-2220A
J5
SW4
SW3
SW2
J3
JP1
J2
CN8
CN9
CN10
CN11
