10
Specifications
Servo 200 Servo 300 Servo 600 Servo 200 Servo 300 Servo 600 Servo 200 Servo 300 Servo 600
Stereo both channel driven
8 ohms 66 Watts x 2 100 Watts x 2 225 Watts x 2 8 ohms 66 Watts x 2 100 Watts x 2 225 Watts x 2 8 ohms 66 Watts x 2 100 Watts x 2 225 Watts x 2
4 ohms 100 Watts x 2 150 Watts x 2 300 Watts x 2 4 ohms 100 Watts x 2 150 Watts x 2 300 Watts x 2 4 ohms 100 Watts x 2 150 Watts x 2 300 Watts x 2
Bridged mono
8 ohms 200 Watts 300 Watts 600 Watts 8 ohms 200 Watts 300 Watts 600 Watts 8 ohms 200 Watts 300 Watts 600 Watts
Signal to Noise Ratio (20Hz-20k) 102dB 102dB 104dB Signal to Noise Ratio (20Hz-20k) 102dB 102dB 104dB Signal to Noise Ratio (20Hz-20k) 102dB 102dB 104dB
Distortion(SMPTE-IM) 0.05% 0.01% 0.04% Distortion(SMPTE-IM) 0.05% 0.01% 0.04% Distortion(SMPTE-IM) 0.05% 0.01% 0.04%
Input sensitivity @8ohms 1.24V(4dBu) 1.24V(4dBu) 1.24V(4dBu) Input sensitivity @8ohms 1.24V(4dBu) 1.24V(4dBu) 1.24V(4dBu) Input sensitivity @8ohms 1.24V(4dBu) 1.24V(4dBu) 1.24V(4dBu)
Voltage Gain 32dB 33dB 34dB Voltage Gain 32dB 33dB 34dB Voltage Gain 32dB 33dB 34dB
Output Circuitry AB AB AB Output Circuitry AB AB AB Output Circuitry AB AB AB
AC Power @1/8 rated power 4ohms, max. 0.5A 0.7A 1.3A AC Power @1/8 rated power 4ohms, max. 0.5A 0.7A 1.3A AC Power @1/8 rated power 4ohms, max. 0.5A 0.7A 1.3A
AC Power @1/3 rated power 4ohms, max. 1.1A 1.7A 3.3A AC Power @1/3 rated power 4ohms, max. 1.1A 1.7A 3.3A AC Power @1/3 rated power 4ohms, max. 1.1A 1.7A 3.3A
AC Power @ rated power 4ohms, max. 3.3A 5.0A 10A AC Power @ rated power 4ohms, max. 3.3A 5.0A 10A AC Power @ rated power 4ohms, max. 3.3A 5.0A 10A
Distortion(typical @4 ohms)
20Hz-20kHz,10dB below rated power
0.01% 0.01% 0.03% 20Hz-20kHz,10dB below rated power 0.01% 0.01% 0.03% 20Hz-20kHz,10dB below rated power 0.01% 0.01% 0.03%
IkHz,rated power 0.1% 0.1% 0.1% IkHz,rated power 0.1% 0.1% 0.1% IkHz,rated power 0.1% 0.1% 0.1%
Frequency Response @8ohms 1Watt 0/-0.5dB:20Hz-20kHz,0/-3dB:5Hz-60kHz Frequency Response @8ohms 1Watt 0/-0.5dB:20Hz-20kHz,0/-3dB:5Hz-60kHz Frequency Response @8ohms 1Watt 0/-0.5dB:20Hz-20kHz,0/-3dB:5Hz-60kHz
Damping Factor(400Hz) 280 280 350 Damping Factor(400Hz) 280 280 350 Damping Factor(400Hz) 280 280 350
Input Impedance 15kohm Unbalanced,30kohm Balanced Input Impedance 15kohm Unbalanced,30kohm Balanced Input Impedance 15kohm Unbalanced,30kohm Balanced
Input Clipping 10Vrms(22dBu) Input Clipping 10Vrms(22dBu) Input Clipping 10Vrms(22dBu)
Cooling Continuously variable speed, fan forced air Cooling Continuously variable speed, fan forced air Cooling Continuously variable speed, fan forced air
Connectors (each channel)
Input: RCA unbalanced and1/4”(6.3mm)TRS, balanced Input: RCA unbalanced and1/4”(6.3mm)TRS, balanced Input: RCA unbalanced and1/4”(6.3mm)TRS, balanced
Output: 5-way Binding post and 1/4” Phone Output: 5-way Binding post and 1/4” Phone Output: 5-way Binding post and 1/4” Phone
Controls AC power switch,Channel 1 and 2 volume Controls AC power switch,Channel 1 and 2 volume Controls AC power switch,Channel 1 and 2 volume
Indicators Power on(blue),Protection(amber) Indicators Power on(blue),Protection(amber) Indicators Power on(blue),Protection(amber)
Signal(green) for each Ch.,Peak(red) for each Ch. Signal(green) for each Ch.,Peak(red) for each Ch. Signal(green) for each Ch.,Peak(red) for each Ch.
Level: , -24 dB, -20 dB, -16 dB, -12 dB, -8 dB, -4 dB, -2 dB. O, +2 dB and +4 dB Level: , -24 dB, -20 dB, -16 dB, -12 dB, -8 dB, -4 dB, -2 dB. O, +2 dB and +4 dB Level: , -24 dB, -20 dB, -16 dB, -12 dB, -8 dB, -4 dB, -2 dB. O, +2 dB and +4 dB
(PEAK).
Protection Short circuit,Thermal,Current limit,DC offset,Current inrush,RF Protection Short circuit,Thermal,Current limit,DC offset,Current inrush,RF Protection Short circuit,Thermal,Current limit,DC offset,Current inrush,RF
protection, Turn on/Turn off muting
Power Requirements 115/230,240VAC,50/60Hz Power Requirements 115/230,240VAC,50/60Hz Power Requirements 115/230,240VAC,50/60Hz
Dimensions(WXHXD) 19”(483mm)X3.5”(89mm)X11.7”(297mm) Dimensions(WXHXD) 19”(483mm)X3.5”(89mm)X11.7”(297mm) Dimensions(WXHXD) 19”(483mm)X3.5”(89mm)X11.7”(297mm)
Net Weight 15 lbs 6.82 kg 20 lbs 9.09 kg 24 lbs 10.91 kg Net Weight 15 lbs 6.82 kg 20 lbs 9.09 kg 24 lbs 10.91 kg Net Weight 15 lbs 6.82 kg 20 lbs 9.09 kg 24 lbs 10.91 kg
