Steiner Optik 8x30 Military/Marine Binoculars - Manual (Page 12)

10
Ba
sic i
ns
tru
ct
io
ns f
or u
se
22
33
44
55
11
66
Attaching the belt attachment:
With ClicLoc System:
To loosen the carrying strap and unlatch the lock, press and hold the marked oval position on the
rubber armouring
11 . The snap fit can now be pulled off and/or inserted. Make sure that the
catch is always facing outwards and that it audibly engages while being inserted.
Without ClicLoc system:
Please loosen one end of the strap from the side loop and feed the strap from the top through
the eyelet.
22 Now pull the carrying strap through the slide loop again and pull firmly on the
strap to tighten it. Repeat these steps to fasten the other end of the strap in the same way.
Attaching the neoprene protection cover and the rain protection cover:
Several rain protection systems may be enclosed with your binoculars that are attached to the
carrying strap. For neoprene protection covers, please ensure that the semicircular opening
on the cover is placed over the focussing wheel
33 . For rain protection covers, the strap
retainer may be threaded laterally through the open eyelet 44 provided for this purpose.
Attaching the objective protection covers:
If your binoculars are equipped with locking ClicLoc objective protection covers, press on the
visible depression to release the cover and pull it out of its retainer
55 . To re-connect it, push
the snap-on fastener back into the retainer until it is secure and audibly engages. Objective
protection covers that are attached to the centre axis are removed by pulling them over the
centre axis
66 .
