31
ENGLISH
15 Energy Saving (Command: j q)
► To reduce the power consumption of the TV. You
can also adjust Energy Saving in picture settings.
Transmission
(j)(q)( )(Set ID)( )(Data)(Cr)
Power Saving
Function
Level
Description
7 6 5 4 3 2 1 0
0 0 0 0
Low
Power 0 0 0 0
Off
0 0 0 0
Low
Power 0 0 0 1
Minimum
0 0 0 0
Low
Power 0 0 1 0
Medium
0 0 0 0
Low
Power 0 0 1 1
Maximum
0 0 0 0
Low
Power 0 1 0 1 Screen Off
0 0 0 0
Low
Power 0 1 0 0
Auto
► Auto is available in TV that supports ‘Intelligent
Sensor’.
Ack
(q)( )(Set ID)( )(OK/NG)(Data)(x)
16 Auto Configuration (Command: j u) (Only RGB
support model)
► To adjust picture position and minimize image
shaking automatically. It works only in RGB (PC)
mode.
Transmission
(j)(u)( )(Set ID)( )(Data)(Cr)
Data 01: To set
Ack
(u)( )(Set ID)( )(OK/NG)(Data)(x)
17 Equalizer (Command: j v)
► To adjust equalizer.
Transmission
(j)(v)( )(Set ID)( )(Data)(Cr)
MSB LSB
0 0 0 0 0 0 0 0
Frequency Data
7 6 5 Frequency 4 3 2 1 0 Step
0 0 0 1st Band 0 0 0 0 0 0 (decimal)
0 0 1 2nd Band 0 0 0 0 1 1 (decimal)
0 1 0 3rd Band ... ... ... ... ...
...
0 1 1 4th Band 1 0 0 1 1 19 (decimal)
1 0 0 5th Band 1 0 1 0 0 20 (decimal)
Ack
(v)( )(Set ID)( )(OK/NG)(Data)(x)
