136
Interior equipment and trunk
On the floor of the luggage compartment
there may be two longitudinal aluminium
rails (CargoTracks™) where accessory
cargo tie down eye can be mounted.
Fitting a lashing eye:
1 Hold it between your forefinger and
middle finger with the ring up.
2 Press down the spring center section
with your thumb.
3 Insert the center section into one of the
holes and move the lashing eye forward
or back slightly to fit it into the middle of
the recess in the rail.
4 Release it.
5 Check that the lashing eye is firmly fitted
by pulling on it.
Items for load anchoring:
• Cargo tie down eye 3.
• Special load straps 3.
Items to keep light objects tidy 3:
• Elastic floor cargo net 3.
• Elastic side cargo net for the right-hand
side of the luggage compartment 3.
The elastic nets may only be used to keep
light objects tidy, not for anchoring.
The floor net should be attached to the
cargo tie down eye that are mounted on the
CargoTracks™. Place the tie down eyes as
far forward and as far back as possible on
the CargoTracks™.
The side netting should be attached to the
two tie down eyes which are included in the
accessory kit and to two of the eyes
mounted on the right-hand CargoTrack™
on the floor.
The cargo tie down eyes, load straps and
elastic nets are stored in the two floor lock-
ers on the right- and left-hand side of the
luggage compartment. The lockers are
opened by lifting the respective fabric loop.
NOTE
Do not place any objects so that the
demisting and antenna elements on the
inside of the window could be damaged.
IB4092
Cargo tie down eye 3 mounted on the lon-
gitudinal rails 3
IB1216
Example of cargo anchoring
IB1215
Elastic cargo net for lighter objects.
