8
L o a d i n g S u p p l i e s
To load supplies into the printer:
1. Turn off the printer.
2. Attach the printer to the vehicle mount.
3. Squeeze the supply bracket and the spring-loaded supply holder. Pull
the hook end of the supply holder and turn it to the left to release the
supply bracket. Pull the bracket up.
Note: The supply holder cannot be removed.
4. Load the supply so it unrolls from the bottom.
5. Lower the bracket so the supply turns freely, then squeeze the supply
bracket and pull and turn the supply holder to the right to lock the supply
roll in place.
Supply Holder
Spring
Supply Bracket
