Product overview
4 KL2602 and KL2622
2.2 Technical data
Technical data KL2602 KL2622
Number of outputs 2 N/O contacts for power contact 2 N/O contacts (potential-free)
Contact material AgCdO
Switching voltage max. 250V
AC
/ 30V
DC
Switching current max. 5 A
Switching capacity max.
with resistive load Alternating voltage:
5 A
250 V
AC
1250 VA
Direct voltage:
5 A
30 V
DC
150 W
Maximum switching current
with inductive load, cos
ϕ=0.4,
L/R=7ms
2 A 250 V
AC
2 A 30 V
DC
Minimum permitted load
(approximate) 10 mA at 5 V
DC
(as supplied)
C
(after a current of approx. 100 mA (or greater) has been switched at
least once)
Reaction time at a rated load Reaction time: max. 10 ms
Release time: max. 4 ms
Bounce time: max. 5 ms
Electrical isolation 500 V
rms
(K-Bus/mains voltage)
K-Bus current consumption 80 mA 85 mA
Bit width in process image 2 A
Service life
Mechanical operating cycles 20,000,000 switching operations
Service life
Electrical operating cycles At least 100,000 switching operations on resistive loads at
250 V
AC
5 A or
30 V
DC
5 A
Permitted switching frequency
at maximum contact load 10 switching operations / minute
Contact resistance max. (new) < 30 mΩ
Insulation resistance (min). 100 MΩ at 500 V
DC
Test voltage between open
contacts 750 V (1 minute between open contacts)
Configuration no address or configuration settings
Weight approx. 85 g approx. 80 g
during
operation -25°C ... +60°C in operation
0°C ... +55°C (according to cULus) for Canada and USA
0°C ... +55°C (according to ATEX, see special conditions) Permissible
ambient
temperature
range
during
storage -40°C... +85°C
Relative humidity 95 % no condensation
Vibration / shock resistance conforms to EN 60068-2-6 / EN 60068-2-27
EMC resistance burst / ESD conforms to EN 61000-6-2 / EN 61000-6-4
Installation position any
Protection class IP20
Approvals CE, cULus, ATEX, GL
