Daktronics All Sport 3000 Series - Manual (Page 58)

Gymnastics Operations 7-1
Section 7: Gymnastics Operations
Sport Insert OG-207640 (Code 04)
Reference Drawings:
Block
Diagram; A/S 5000 BB, VB, & WR #1............................................ A-124686
Block Diagram; A/S 3000 or 5000 BB, VB, & WR #2 .............................. A-125415
Block Diagram; A/S 5000 BB, VB, & WR #4............................................ A-125417
Insert; 0G-207640, A/S 3100 Gymnastics ............................................... A-207640
Refer to Appendix C for a list of the codes of the All Sport 2500 console and which code for
the 3000 system takes its place.
The sport insert and block diagram drawings are located in Appendix A.
Refer to the information in Section 2: Basic Operation to start the console and use the sport
insert. Read Basic Operation carefully to fully understand the following operation
instructions. The gymnastics insert drawing, A-207640, displays the function for each key on
the All Sport 3000 series consoles during gymnastics mode. The block diagram drawing,
A-124686, displays the installation of the All Sport 3000 series control consoles to the main
scoreboard and other Daktronics products.
If you lose or damage an insert, use a photocopy of the insert until you can order a
replacement.
If you do not know the code number to enter for your scoreboard, refer to Appendix B in this
manual. If you do not know the model number of your scoreboard, refer to the installation and
maintenance manual provided with the scoreboard.
7.1 Gymnastics
Competitor
The <COMPETITOR > key is used to enter the competitor number.
LCD Display Action
Competitor
nnn
n = current setting
Press the <COMPETITOR > key to display the current
competitor number.
Enter the desired number on the number pad and press
<ENTER*>.
