ITEM NO. PART NUMBER DESCRIPTION QTY.
73 011-0407022 3/8"-16UNC X 1.00" HHB (WZ) 4
74 011-0107037 3/8"-16UNC X 1.25" HHB (WZ) 2
75 011-0107033 38-16UNC X 1.5" HHB (WZ) 2
76 011-0107022 3/8"-16UNC X 5.00" HHB (WZ) 4
77 011-0407042 1/2"-13UNC X 1.00" HHB (WZ) 16
78 011-0407018 1/2"-13UNC X 2.50" HHB (WZ) 10
79 011-0407055 1/2"-13UNC X 4.75" HHB (WZ) 8
80 011-0107014 1/2"-13UNC X 5.00" HHB (WZ) 8
81 011-0102030 1/2"-13UNC X 5.25" HHB (WZ) 4
82 011-0107021 1/2"-13UNC X 5.50" HHB (WZ) 4
83 012-0104008 3/8"-16 UNC THIN NYLOCK NUT (WZ) 4
84 012-0304011 1/2"-13 UNC THIN NYLOCK NUT (WZ) 50
85 021-0003008 DECAL COMMERCIAL MAINTENANCE 1.50 X 6.69 1
86 021-0003113 DECAL PINCH POINT 1.63" X 3.25" (VERTICAL) 2
87 021-0003135 DECAL WARNING 1.50" X 6.69" 1
88 021-0003221 DECAL HOIST 2.50" X 9.13" 2
89 021-0003282 DECAL: SPOTTER 1.63" X 3.25" (VERTICAL) 2
90 021-0003543 DECAL MOVING PARTS 1.20" X 2.38" (VERTICAL) 2
91 021-0003599 DECAL: DUAL ACTION SMITH WARNING 1
92 021-0003600 DECAL: DUAL ACTION SMITH DANGER 1
93 021-0003627 DECAL HOIST 2.12" X 7.75" 2
94 021-0003763 DECAL: CF-3754 SAFETY TIER INDEXING-1 (1-7) 2
95 021-0003764 DECAL: CF-3754 SAFETY TIER INDEXING-2 (1-7) 2
96 021-0003783 CF-3754 WEAR STRIP DECAL 2
97 SERIAL # DECAL DECAL HOIST SERIAL # 1.63" X 2.63" 1
PARTS LIST
NOTE: SOME OF THESE PARTS MAY COME PRE-INSTALLED
CF-3754 ASSEMBLY
OWNER'S MANUAL
PAGE 26
