Kawai CA97 - Manual (Page 64)

64
Set
tings
Basic Settings
The Basic Settings menu contains settings to adjust the pitch, tuning, and general sound of the instrument.
This menu also allows favourite panel settings to be stored, or reset back to the original factory configuration.
„Basic Settings
No. Setting Description Default setting
1 Key Transpose Raise or lower the pitch of the keyboard in semi-tone steps. 0 (C)
2 Song Transpose Raise or lower the pitch of the recorder/MIDI song in semi-tone steps. 0
3 Tone Control Change the EQ settings of the instrument’s sound. Off
4 Speaker Volume Change the maximum volume level of the speaker output. Normal
5 Line In Level Adjust the input volume of the Line In connectors. 0 dB.
6 Wall EQ* Optimise the instrument’s speaker system based on instrument placement. Off
7 Tuning Raise or lower the pitch of the instrument in 0.5 Hz steps. 440.0 Hz
8 Damper Hold Change the effect of pressing the sustain pedal on organ, string, etc. sounds. Off
9 Split Enable the ‘Split Mode’ function. Off
10 Four Hands Enable the ‘Four Hands Mode’ function. Off
11 LCD Contrast Adjust the contrast of the instrument’s LCD display. 5
12 Startup Setting Store current panel settings as the default (power-on) configuration. -
13 Factory Reset Restore all panel settings to the original factory configuration. -
14 Auto Power Off Enable/disable the instrument’s Auto Power Off energy saving function. -
* The Wall EQ setting is available on the CA97 model only. Settings page numbers shown will differ on the CA67 model.
* Default settings will be shown in the first LCD display illustration (i.e. Step 1) for each setting explanation below.
„Entering the Basic Settings menu
While the normal playing mode screen is shown in the LCD display:
Press the FUNCTION button (ENTER).
The Function menus will be shown in the LCD display.
Press the FUNCTION button (ENTER) again to enter the Basic
Settings menu.
„Selecting and adjusting the desired setting
After entering the Basic Settings menu:
Press the d or c buttons to move the selection cursor over the
desired setting.
Press the e or f buttons to adjust the selected setting.
* To reset the current setting to the default value, press the e and f
buttons simultaneously.
dc buttons:
Move selection cursor.
ef buttons:
Adjust selected setting.
