2
The Euro Charger, Model 091-90-xx is a compact, completely automatic single channel
battery charger designed specifically for the fire service and emergency vehicles. Of rugged
construction, the charge is made to withstand the shock and vibration encountered in
vehicle mounted equipment. Utilizing components which meet international safety require-
ments makes this charger ideal for worldwide applications.
BATTERY CHARGER FEATURES
1. The Euro Charger Automatic Battery Charger should be installed in an area with
adequate ventilation.
2. Mount the charger using the four holes provided.
3. Connect the wiring from the batteries to the output terminal strip.
4. Double check battery wiring. Verify that battery voltage appears at the charger output
terminals.
5. Set the voltage selector to either the 115 volt or 230 volt position to match the input source
available.
6. Connect the input power to the input power terminal strip and energize charger.
7. Verify that power indicator is illuminated and charger is charging.
Completely automatic operation, charges battery on demand
Input voltage, switch selectable, 115 volt or 230 volts
Output voltage regulated, eliminates overcharging battery
Output, current limited to protect charger from overloading
Optional charge indicators
INTRODUCTION
INSTALLATION
