Designing Labels Using LDS
Chapter 4
4-16
438 Operator’s Manual - 880052-0100
For Example: If a TCI of 40 is selected the CGN will be omitted by entering nothing for the
CGN and surrounding the parameter with the comma delimiter.
1,200,200,10,40,,0,0,100,1
Bar Code Symbologies
SYMBOL
CGN
VALUE
RATIO
HEIGHT SPACING
FO **
Code 39
2
3
5
8
2:1
3:1
5:2
8:3
1
1
1
1
2
2
2
3
0123
0123
0123
0123
I 2 of 5
2
3
5
2:1
3:1
5:2
1
1
1
-
-
-
0123
0123
0123
UPC / EAN *
-
40 %
1
-
0123
UPC Readable *
-
40 %
1
-
0123
Code 128 & UCC / EAN 128 *
-
40 %
1
-
0123
Codabar
2
3
5
2:1
3:1
5:2
1
1
1
-
-
-
0123
0123
0123
Code 93
-
2:1
1
-
0123
AS-10
-
2:1
1
-
0123
MSI (Modified Plessey)
-
1:1
1
-
0123
Table 4-7
CGN—Bar Code Symbologies
* These Symbols must use the CMX or CMY multipliers by 2 to produce an 80% ratio.
** The “FO” field represents the available Field Orientation or print rotation.
4.6.7
FO
(Field Orientation)
This parameter defines the rotation of the format field on the label. The point of rotation is
determined from the Field Justification parameter.
0
0 degrees (normal rotation)
1
180 degrees (upside-down rotation)
2
270 degrees (right rotation)
3
90 degrees (left rotation)
4.6.8
FJ
(Field Justification)
This parameter defines the justification of the format field on the label.
0
Left Justified above the base-line
1
Right Justified above the base-line
2
Left Justified below the base-line
3
Right Justified below the base-line
4
Centered above the base-line
5
Centered below the base-line
