Repair Section
55
8.5 Removal of Electrical Parts
WARNING
• Disconnect the power supply from the CM 12 unit before performing any service. Beware
that some residual voltages may remain in the unit immediately after the power is
disconnected.
(1) For unit serial number from 0415XXXXC12 to Present *
*:Please refer to page 2 for the position of the name plate showing the serial number on the unit.
ILL00959-00
Capacitor for
Condenser
Condenser
Relay
Wire
Terminal for
Power
Terminal for
Signal
Capacitor for
Condenser
Fan Motor
Capacitor for
Evaporator Fan Motor
Support
Box
Relay Board
