Pacific Cycles CARRYME DC - Manual (Page 4)

5. The CarryMe DC has three modes of propulsion:
i. As a bicycle for extended range, pedal only without the motor
turned on.
ii. Power assist, throttle and pedaling combined, for next best for
range.
iii. Throttle only for shortest range.
6. Press the red button on the battery to turn off power.
7. On hard acceleration or uphill the green light on the throttle will go out
even if you have a full charge. As you are using the CarryMe DC the green
light will eventually stay off and the yellow will be on. This shows you
have about 1/2 power remaining. Once the yellow light stays off and the
red light is on, the power is almost used and you should use the motor as
little as possible until you can recharge it. Always charge the battery as
soon as possible once you have run it all the way down.
Maintenance & Charging
1. Only use the charger supplied with the bike. Any other charger will void
the warranty.
2. Check your local voltage to ensure it conforms to the charging voltage.
3. Attach the charger to the bike first and then plug it into the charging
source.
4. The red light will appear during charging. The green light will appear
upon full charge.
5. When finished charging, unplug the charger from the socket first and
then from the bike.
6. Keep charger away from combustibles and liquids. Do not cover it.
7. The lithium-ion battery does not have a memory so for maximum life
keep the battery fully charged at all times. Do not leave the battery
discharged for longer than 24 hours since it will begin the degrade
battery life.
8. When storing the bike, store with a fully charged battery in a dry cool
location. For maximum battery life, charge the battery every couple of
weeks.
9. Do not expose the bike to strong static electricity or magnetic fields.
