A-13
Front Attachment
42-011 SAND PLOW PARTS LIST
REF# PART# DESCRIPTION QUANTITY
1 42-346 Lift Assembly 1
2 HNTL-12-13 Lock Nut 1 /
2
- 13 4
3 HB-38-16-350 Bolt 3 /
8
- 16 x 3 1 /
2 (part of main frame) 2
HWL-38 Lock Washer 3 /
8
2
HN-38-16 Nut 3 /
8
- 16 2
4 HCP-12-150 Clevis Pin 1 /
2
x1 1 /
2
2
5 27-049 Left Pusher Bar 1
6 HB-38-16-250 Bolt 3 /
8
- 16 x 2 1 /
2
2
HW-38 Washer 3 /
8
4
HNTL-38-16 Lock Nut 3 /
8
- 16 2
7 HB-12-13-200 Bolt 1 /
2
- 13 x 2 2
HMB-12-14 Machine Bushing 1 /
2
x 14GA 8
8 42-836 Spacer 2
9 80-006 Rod End 4
HNJ-12-20 Jam Nut 1 /
2
- 20 4
10 27-073 Lift Rod 2
11 27-017 Aluminum Sand Plow Blade 1
13-352 Steel Sand Plow Blade 1
12 HB-38-16-125 Bolt 3 /
8
- 16 x 1 1 /
4
2
HW-38 Washer 3 /
8
2
HWL-38 Lock Washer 3 /
8
2
HN-38-16 Nut 3 /
8
- 16 2
13 HB-12-13-300 Bolt 1 /
2
- 13 x 3 2
HNTL-12-13 Lock Nut 1 /
2
- 13 2
14 HB-38-16-100 Bolt 3 /
8
- 16 x 1 4
HNFL-38-16 Flange Whiz Lock Nut 3 /
8
- 16 4
15 13-167 Wear Blade 1
16 27-050 Right Pusher Bar 1
17 HHP-18 Bridge Pin 1 /
8
2
18 42-348 Rod 1
19 42-347 Lift Handle(includes Ref# 20) 1
20 18-221 Flange Bushing 2
21 HMB-34-14 Machine Bushing 3 /
4
- 14GA 1
22 HP-18-150 Cotter Pin 1 /
8
x 1 1 /
2
1
23 15-019 Grip 1
24 HB-12-13-200 Bolt 1 /
2
- 13 x 2 2
SAND PLOW INSTALLATION
1. Assemble (Ref# 5 and 16) Pusher Bars to (Ref# 11) Plow using (Ref# 12 and 13) hardware. There are 2 holes to
bolt (Ref# 12) hardware in. Using hole closest to the blade will result in a shallow cut, whereas using the hole
furthest from the blade will result in a deeper cut. The slot on the pusher bar is for a more fine tuned adjustment.
2. Assemble the (Ref# 1) Lift Assembly to the Main Frame using the two studs that are under the frame and below
the front of the console.
3. Attach the (Ref# 19) Lift Handle to the lift assembly using (Ref# 21 & 22) Cotter Pin and Machine Bushing. Using
(Ref# 18 & 9) Rod and Yoke attach the handle to the lift assembly.
4. Put (Ref# 9) Rod Ends onto (Ref# 10) Lift Rods with Jam Nut first. Adjust to equal lengths. Bolt Lift Rods to Lift
Arms with Ball Joints to the outside. Bolt from outside with the
1 /
2
" Machine Bushing between Rod End and Lift
Arm and the 1 /
2
- 13 nut on the inside. Use (Ref# 7) Hardware.Use the spacer (Ref# 8) between Rod end and lift
assembly.
5. Slide Plow under machine and connect to machine. Use (Ref# 4 & 17) Clevis Pin and Bridge Pin.
6. Lift up the plow using the bottom hole in the Lift Rod as a starting point. Secure to the Pusher Bars. Use (Ref# 6)
hardware. For maximum blade clearance use the second hole from the front of the pusher bar. The three holes
in the lift rods are for adjusting the hand lever. The top hole moves the lever forward. Each hole down moves hte
lever to the rear of the machine.
7. For fine tuning of blade height off ground twist (Ref# 9) rod end on (Ref# 18) rod. Twisting the rod end out will
increase down pressure. Twisting the rod end onto the rod will decrease down pressure.
