Tsunami SoundCar User’s Guide
Page 34
CVs 23 and 24 may be set to any value from ‑127 to +127. Positive values
produce slower throttle responses, while negative values result in quicker
throttle responses.
If the sum of the values of CV 23 and CV 3 exceeds 255, then the final
consist acceleration rate will be set to the maximum value of 255. If the sum
of CVs 23 and 3 is negative, the final consist acceleration rate will be set to
the minimum value of 0.
To set a positive value, simply program the CV with the desired value from 0
to 127. To set a negative value, first remove the negative sign from the value
and add 128. Thus, to program a value of ‑5, add 5 to 128 (5 + 128 = 133),
and program the total of 133 into the appropriate CV.
Notes: A value of 128 is equivalent to a setting of 0 and will have no effect.
When operating Intelligent Consisting, it is best to leave the values in CVs
23 and 24 at 0 unless all of the locomotives pulling the cars are set up using
advanced consisting.
Consist Programming
