3.2 The Rear Panel
HOST 2
100- 240 V ~, 0.5 A , 50/ 60 Hz T 2A , 250 VAC HDMI 1
HOST 1 CONTROL
PS/2 1
CAUTION! Replace with same type and rating fuse .
PS/2 2 HDMI 2 HDMI 3 HDMI 4 HDMI 5 HDMI 6 HDMI 7 HDMI 8
1 2 3 4 5 6 7 8
DISPLAY 1 DISPLAY 2
1 2
USB 2.0
CONTROL
OUT
IN
PS2 Option
(Ports 1 and 2)
RJ45
Control OUT/IN
USB-B and
Audio IN (1-8)
HDMI IN
(1-8)
AC IN ON/OFF
Three USB 1.0/ One USB 2.0
(Users 1 & 2)
Audio OUT (1-2) Firmware
Upgrade Ports
Display
OUT (1-2)
3.3
Cable KIT-000063-R
PS/2 to PS/2 Male, 6' (CBL-000006-006FR) – Qty 4
USB A-B, 6' (CBL-000015-006FR) – Qty 8
HDMI to DVI, 6' (CBL-000030-002FR) – Qty 10
3.5mm M/M Audio, 6' (CBL-000016-006FR) – Qty 8
