LG 55TC3CG-H 55" 4K UHD HDR Touchscreen Commercial Monitor - Manual (Page 33)

33
ENGLISH
PRODUCT SPECIFICATIONS
The product specifications below may be changed without prior notice due to upgrade of product functions.
“ ” refers to alternating current (AC), and “ ” refers to direct current (DC).
LCD screen Screen type Thin Film Transistor (TFT)
Liquid Crystal Display (LCD) Screen
Pixel pitch 0.315 mm (H) x 0.315 mm (V)
Video signal Maximum resolution HDMI1,2 / DisplayPort: 3840 x 2160 @ 60 Hz
OPS: 3840 x 2160 @ 30 Hz
- This may not be supported on some OS or graphics card types.
Recommended resolution HDMI1,2 / DisplayPort: 3840 x 2160 @ 60 Hz
OPS: 3840 x 2160 @ 30 Hz
- This may not be supported on some OS or graphics card types.
Horizontal frequency HDMI1,2 / DisplayPort(PC): 30 kHz to 136 kHz
HDMI1,2 / DisplayPort / OPS(PC): 30 to 83 kHz
Vertical frequency HDMI1,2 / DisplayPort / OPS(PC): 58 Hz to 62 Hz
Synchronization Separate Sync, Digital
Input/output ports LAN, HDMI IN1, HDMI IN 2, DP IN/OUT, RS 232C IN/OUT,
USB 2.0 IN, IR & LIGHT SENSOR, AUDIO OUT, TOUCH USB,
SPEAKER OUT, OPS
Embedded battery Applied
Power Rated power 100-240 V~ 50/60 Hz 1.7 A
Power consumption On Mode: 105 W (Typ.)
Sleep Mode: ≤ 0.5 W
Standby Mode: ≤ 0.5 W
Audio RMS Audio Output 10 W + 10 W (R + L)
Input Sensitivity 0.7 Vrms
Speaker Impedance 6 Ω
Environmental
Conditions
Operating Temperature 0 °C to 40 °C (32 °F to 104 °F)
Operating Humidity 10 % to 80 %
Storage Temperature -20 °C to 60 °C (-4 °F to 140 °F)
Storage Humidity 5 % to 85 %
Dimensions (Width x Height x Depth) / Weight 1,276.4 mm x 751.9 mm x 44.9 mm / 34.5 kg
(50.2 inches x 29.6 inches x 1.7 inches / 76 lbs)
* Touch Screen
OS (Operating System) Windows 8.1 / 10, Linux kernel above v3.0 40 Points
Space between touches: at least 20 mm (0.7 inches) or more
