20
BDR-XD08B / BDR-XD08S / BDR-XD08G En
This unit can be added without shutting down or rebooting the computer. Connect the unit to the
supplied USB cable.
1 Confirm that your computer (PC) has an available USB port.
2 With your Windows ® or Mac ® operating system running, use the supplied USB cable to
connect this unit to the PC.
Caution
• Do not disconnect the USB cable during data transfers.
• Do not disconnect the USB cable during PC startup or any operation with the unit.
DC IN 5V DC IN 5V
Computer
(PC)
This unit
USB 3.0 port
recommended
USB 3.0
USB cable (supplied)
USB Type-C
exchange
cable
(supplied)
USB cable
(supplied)
The L-shaped USB cable can connect to the drive in either direction, but when plugged in with the
cord extending to the right, the cable blocks the AC Adapter Connector. To avoid damage if using an
optional AC adapter, plug in the USB cable so the cord extends to the left.
Note
• Connection to a USB 3.0 port is recommended, since when a USB 3.0 cable is connected to a USB
2.0 port, the connection will be limited to USB 2.0 performance standards.
• This unit can operate with USB 1.1 but will not provide optimum performance.
• Connecting this unit through a USB hub or using unspecified cables may not achieve proper
operation.
• If power is insufficient when using a USB port, connect an AC adapter (not included) through the
DC IN connector on the unit’s rear panel and plug into a wall outlet to deliver power. Connect the
USB cable (included) after connecting the AC adapter for proper operation. For more details about
the AC adapter connection, visit or contact
https://www.pioneerelectronics.com/PUSA/
Phone: 1-800-421-1404
Connection
