X To remove: press buttons : on luggage
cover ; simultaneously and remove it in
the direction of the arrow.
X To install: insert luggage cover ; and
push it in the opposite direction to the
arrow until it engages.
Safety net (CLS Shooting Brake)
Important safety notes
G
WARNING
On its own, the safety net cannot secure or
restrain heavy objects, items of luggage and
heavy loads. You could be hit by an unsecured
load during sudden changes in direction,
braking or in the event of an accident. There
is an increased risk of injury or even fatal
injury.
Always store objects so that they cannot be
flung around. Secure objects, luggage or
loads against slipping or tipping over, e.g. by
using lashing material, even if you are using
the safety net.
It is important to use a safety net if you load
the vehicle with small objects above the seat
backrests. For safety reasons, always use a
safety net when transporting a load.
The safety net is located in the stowage space
under the luggage compartment floor
(
Y page 318).
X Open both Velcro fasteners and remove the
safety net.
X Unroll and unfold the safety net.
The joints on the upper and lower guide rod
should engage audibly.
The corresponding lashing eyelets for tight-
ening the safety net are in the luggage com-
partment in front of the rear bench seat
(
Y page 311).
Attaching and tightening the safety net
X To attach and tighten: insert guide
rod : into bracket ;.
X Attach spring hook = to the lashing eyelet
or bracket (vehicles wit EASY-PACK load-
securing kit (
Y page 316)) and pull down
on the loose end of the lashing strap until
the safety net is taut.
X After driving a short distance, check the
tension of the safety net and retighten it if
necessary.
X To loosen and detach: pull belt
clamp ? up to reduce the tension in the
lashing strap.
X Remove spring hook = from the lashing
eyelet or bracket (vehicles with EASY-PACK
load-securing kit (
Y page 316)).
X Detach guide rod : from bracket ;.
X To stow: press the red button on the upper
and lower guide rod.
X Fold the safety net and roll it up.
X Close the two Velcro fasteners on the
safety net holder.
314
