Page 319
X
To install: insert two brackets A into the
left or right loading rail (
X
Press release button : of the luggage
holder and pull the strap out slightly.
X
Insert luggage holder ; into brackets A
and, while doing so, press release button
= and push the luggage holder downwards
until it engages.
X
Press release button : of the luggage
holder and pull the strap out in the direction
of the arrow.
X
Place the load between the strap and the
luggage compartment side wall.
X
Using one hand, press locking button : of
the luggage holder.
X
With your other hand, let the strap go slowly
until the load is secured.
X
Make sure that locking button ? on brack-
ets A is pressed.
This keeps brackets A in place on the
loading rail.
X
To remove: press release button = on
respective bracket A and remove luggage
holder ; by pulling upwards and out.
Telescopic rod
The telescopic rod can be used to secure the
load against the rear seats to prevent it from
moving around.
X
To install: insert one bracket ; into both
the left and the right loading rails and slide
it to the desired position (
X
Insert telescopic rod : into brackets ;
and, while doing so, press release but-
ton ? and push the rod downwards until it
engages.
X
Make sure that locking button = on brack-
ets ; is pressed.
This keeps brackets ; in place on the
loading rail.
X
To remove: press release button ? on
respective bracket ; and remove tele-
scopic rod : by pulling it upwards and out.
Stowage well under the boot floor
!
Remove the handle again before closing
the boot lid and snap it in tightly to prevent
the handle flap from protruding. Otherwise,
you could damage the handle.
The TIREFIT kit, the vehicle tool kit, etc. are
located in the stowage compartment.
X
To open: pull handle : up.
Stowage areas
317
Stowing and features
