Draco KVM Extender
28
2013-08-13
3.6.19 Model L- / R481-BHXC
CPU Module
CON Module
2
3
1
2
3
1
Rear View
Rear View
1
Connect to interconnect cable
2 Service
Port
3
To CPU: HDMI
1
Connect to interconnect cable
2 Service
Port
3
Connect to HDMI monitor
Pos: 33 /806-IHSE/Beschreibung/Geräteansichten/481-xx/Typ L- / R481-BHXS @ 9\mod_1367833945591_6.doc @ 71854 @ 3 @ 1
3.6.20 Model L- / R481-BHXS
CPU Module
CON Module
2
3
1
2
3
1
Rear View
Rear View
1
Connect to interconnect cable
2 Service
Port
3
To CPU: HDMI
1
Connect to interconnect cable
2 Service
Port
3
To CPU: HDMI
The video only modules without USB-HID connection are only meant for
the use with basic extender modules.
