General Backup Overview
The General Backup screen is used for performing bulk backup of video recorded by all cameras for a
selected period, or periods, to a specified storage location.
Hour / Minutes
Recording data displays in hourly (24 vertical columns) and 10-minute (6 horizontal rows) segments.
Green cells indicate time with recorded video. Red cells indicate time selected for backup.
Backup Status
Displays the size of all video currently selected for backup, the available size of the media currently
selected for backup to, and the dates and times of video currently selected for backup.
Fixed HDD
Display all Hard Drives
1. In the Display screen, click Backup .
2. Select a date to back up using the calendar. Dates highlighted in blue contain recorded data.
3. Select the blocks of time to back up using the Hour/Minute grid. Blocks of time with recorded video
are highlighted in green. Blocks of time selected for backup are highlighted in red.
4. To select video from another date, click your desired date in the calendar and repeat step 3.
5. Select the backup drive or drives in the Select Backup Media section, or click Network Drive , or
Browse . When selecting the CD-ROM drive you must specify the number of CDs to use for
backup.
6. Click Backup Order to set the backup order.
7. Select the Include Viewer check box to include the Backup Viewer Application.
8. Click Start Backup to begin the backup process.
Calendar
Display all Hard Drives Select Additional Drive/Folder
Select Remote Network Location
Define Drive Priority
