PELLET STOVES Chapter 3
INSTALLATION AND USE MANUAL page
22
Installation and assembly Technical service - Rights reserved MCZ S.p.A. - Reproduction prohibited
Technical characteristics
Polar Nova Athos Power Hydro
Overall thermal power (total/water) Max. 23.7 kw (20382 kcal/h) / 16.2 kw / 7.5 kw
Overall thermal power (total/water) Min. 6.2 kw (5332 kcal/h) / 3.7 kw / 2.5 kw
Yield at maximum 92 %
Yield at minimum 93 %
Temperature of exhaust smoke at maximum 250°C
Temperature of exhaust smoke at minimum 100°C
CO at 13%O
²
at minimum and maximum 0.055 — 0.018%
CO
2
at minimum and maximum 5.5% – 11.9%
Mass of smoke at minimum and maximum 7.3 – 13 g/sec
Minimum draught at maximum power 0,10 mbar – 10 Pa
Minimum draught at minimum power 0,05 mbar – 5 Pa
Hopper capacity 52 lt
Fuel pellet type Pellet diameter 6-8 mm. Length range 5-30 mm
Pellet consumption per hour Min ~ 1 kg/h * Max. ~ 5 kg/h *
Operating time between re-fuelling At min~ 33 h * At max. ~ 7 h *
Heatable volume m 3 510/40 – 582/35 – 679/30 **
Combustion air inlet Ø 50 mm.
Smoke outlet Ø 80 mm.
Maximum absorbed electrical power Max 320 W – Med 120 W
Power supply frequency and voltage 230 Volt / 50 Hz
Net weight 200 Kg.
Weight with packaging 210 Kg.
*Data that may vary depending on the type of pellets used.
**Heatable volume based on demand of cal/h for m
3 40-35-30 (respectively 40-35-30 Kcal/h for m 3 )
Appliance suitable for installation in a shared flue.
