16
Playback format information display
Press the INFO button on the remote control during playback to
show playback format information.
Example when the playback source is USB, COAX1, COAX2,
OPT1 or OPT2
o The input signal and playback signal displays will be the same
when the upconversion setting is “OFF”.
PCM DSD
44. 1kHz 11. 2MHz
Input signal sampling
frequency Playback sampling
frequency
Playback signal
format Input signal
format
Example when the playback source is NET or Bluetooth
LDAC PCM
48kHz 192kHz
Input signal sampling
frequency Playback sampling
frequency
Codec
Playback signal
format
Volume display
Two types of volume can be shown: STEP and dB.
This is set by the VOLUME TYPE setting (page 23).
The volume setting shown will be enlarged when you turn this unit’s
VOLUME knob.
VOLUME TYPE set to “STEP (0-100)”
Display example
VOL.
36
The maximum volume level is 100 and the minimum level is
0. Before connecting headphones, set the VOLUME knob to its
minimum value (0). Failure to do so might cause sudden loud
noises, which could harm your hearing or result in other trouble.
Display (continued)
VOLUME TYPE set to “dB”
Display example
VOL.
-62
.0dB
The maximum volume level is 0 and the minimum level is −∞
(negative infinity). Before connecting headphones, set the
VOLUME knob to its minimum value (−∞). Failure to do so might
cause sudden loud noises, which could harm your hearing or
result in other trouble.
The set output level is shown when LINE OUT LEVEL is set to “FIXED
0dB” or “FIXED +6dB”.
Example when VOLUME TYPE set to “dB”
USB
+ 0.0
dB
o If VOLUME TYPE is set to “STEP (0-100)”, “VOL. 86” will be shown
when set to “FIXED 0dB” and “VOL. 90” will be shown when set to
“FIXED +6dB”.
When headphones are not connected and LINE OUT LEVEL is set to
“OFF”, “VOL. 0” or “−∞ dB” will be shown.
Example when VOLUME TYPE set to “dB”
USB
− ∞
dB
When headphones are not connected and LINE OUT LEVEL is
set to FIXED or OFF
Turning the VOLUME knob will cause the following to be displayed.
LINE OUT LEVEL set to FIXED
VOL.
FIXED
LINE OUT LEVEL set to OFF
VOL.
OFF
