Draco major
126 2011-10-11
6.2.2 KVM-Switch Function
You have the following possibilities to access the menu:
OSD
The menu KVM Matrix will be opened, if you login to the OSD and the
function KVM Listview in Configuration > System is activated.
The complete and current switching status is shown in this view.
Menu KVM-Switch
The following color combinations are available:
Color CPU
Port Color CON
Port Description
Green n.c. CPU port not connected,
video can be connected to another console
Green Yellow CPU port not connected,
video can be connected to the own console
