VIVOTEK - A Leading Provider of Multimedia Communication Solutions
User's Manual - 139
3. Timeline Panel: This panel appears when Playback is initiated.
Starting from left to right, timeline control functions will be described as follolws:
1. Time Search: Click on the current date to open a calendar. If you want to review videos
recorded in another day, select it from the calendar.
Timescale is adjustable (minutes, hours, days, to a max. of 3 days) so you can easily find the
required time period and begin playback from that point.
Histogram
Adjustment
Export
Speed Control
Playback Timeline & Histogram
Playhead
Synchronous
Playback Control Bu
tt
on
Time Search
Events
Highlights
06:44:23
Mouse-over
indicator
Return to Live
Drag to move along
timeline
Blue: days with recordings.
Orange bottom line: Today.
White: days with no recordings.
