Wagon
X To open: press bag hook : (arrow).
Bag hook : slides out.
X To close: press bag hook : until it
engages.
EASY-PACK cargo compartment cover
Important safety notes
G
WARNING
On its own, the cargo compartment cover
cannot secure or restrain heavy objects,
items of luggage and heavy loads. You could
be hit by an unsecured load during sudden
changes in direction, braking or in the event
of an accident. There is an increased risk of
injury or even fatal injury.
Always store objects so that they cannot be
flung around. Secure objects, luggage or
loads against slipping or tipping over, e.g. by
using tie downs, even if you are using the
cargo compartment cover.
! When loading the vehicle, make sure that
you do not stack the load in the cargo
compartment higher than the lower edge of
the side windows. Do not place heavy
objects on top of the cargo compartment
cover.
The cargo compartment cover and the cargo
net are attached to anchorages on the right
and left in the cargo compartment as a
combined cargo cover and net.
When the tailgate is opened, the cargo
compartment cover is automatically raised to
make loading easier. It is automatically
lowered again when the tailgate is closed.
When the cargo compartment cover is
clipped in, there should be no objects
obstructing the downwards movement of the
cover in the cargo compartment when the
tailgate is closed. The cargo compartment
cover will otherwise be raised again.
Extending/retracting the cargo
compartment cover
X To extend: pull cargo compartment
cover : back by grab handle ; and clip
it into the retainers on the left and right.
X To retract: unhook cargo compartment
cover : from the retainers on the left and
right and guide it forwards by grab
handle ; until it is fully retracted.
Stowage areas
307
Stowage and features
Z
