Cigarette lighter, Stowage and features, Features – Mercedes-Benz 2013 E Class Coupe User Manual
Page 321
X
To open: slide cover : forwards until it
engages.
X
To remove the insert: grasp insert = by
the notch at the side and lift it up ; and
out.
X
To re-install the insert: press insert =
into the holder until it engages.
X
To close: briefly press cover : at the
front.
The cover moves back.
i
You can remove the ashtray insert and
use the resulting compartment for
stowage.
Rear-compartment ashtray
X
To open: briefly press cover ; at the top.
The ashtray opens.
X
To remove the insert: press release
button = and lift the insert up and out.
X
To install the insert: install insert : from
above into the holder and press down into
the holder until it engages.
Cigarette lighter
G
WARNING
You can burn yourself if you touch the hot
heating element or the socket of the cigarette
lighter.
In addition, flammable materials can ignite if:
R
the hot cigarette lighter falls
R
a child holds the hot cigarette lighter to
objects, for example
There is a risk of fire and injury.
Always hold the cigarette lighter by the knob.
Always make sure that the cigarette lighter is
out of reach of children. Never leave children
unsupervised in the vehicle.
Your attention must always be focused on the
traffic conditions. Only use the cigarette
lighter when road and traffic conditions
permit.
X
Turn the SmartKey to position
2 in the
X
To open: slide cover : forwards until it
engages.
X
Press in cigarette lighter ;.
Cigarette lighter ; will pop out
automatically when the heating element is
red-hot.
X
To close: briefly press cover : at the
front.
The cover moves back.
Features
319
Stowage and features
Z
