Appendix A 987396 Using the Daq Configuration Applet with ZonicBook A-3
The following descriptions apply to the preceding figure.
• Device Name: The Device Name field is displayed with the default device name. The field can be
changed to any descriptive name. This device name is the name to be used with the daqOpen function
to open the device.
• Device Type: The Device Type field indicates the device type that was initially selected. However, it
can be changed here if necessary.
• Serial Number: The device serial number is used in the Auto IP Address Setting process.
• IP Address Setting Panel: From this panel the user can select one of two radio buttons. The first is
Auto IP Setting. If selected, the software will automatically derive the Internet Protocol Address. To
do so, the serial number of the device must be entered in the Serial Number field. The resulting IP
address will appear in the IP Address text box.
The second radio button is labeled Manual IP Setting. This feature can be used when the IP address
is already known. When the “manual” radio button is selected the desired address can be entered into
the text field.
• OK: Click on the <OK> button to store the configuration and exit the current dialog box.
• Cancel: Click on the <Cancel> button to exit the current dialog box without storing any changes.
• Apply: Click on the <Apply> button to store the configuration. Or you can click on the
Test Hardware tab.
Quick Guide to Using the Daq Configuration Applet
To Open the Daq Configuration Applet:
a. Open the Control Panel by navigating from the Windows Desktop as follows:
Start Menu ⇒ Settings ⇒ Control Panel
b. Double-click the Daq Configuration icon.
To Add a ZonicBook/618E to the list of installed devices:
a. Select the Computer in the device tree.
b. Click the <Add Device> button.
c. Select ZonicBook618E from the list of devices, as applicable.
d. Click the <OK> button.
Note: The following pertains to ZonicBook/618E configuration. Before starting, be aware that the devices will
have default names, for example, ZonicBook618E_0. If desired, you can change the device name.
To set the properties of a ZonicBook/618E, which is connected to a dedicated network:
a. Enter the serial number of the ZonicBook/618E.
b. Select the Auto IP Setting Radio button. The IP address of the ZonicBook/618E will
automatically be calculated and displayed in the IP Address field.
