11.6 AF auxiliary light (AF-BEAM)
If the AF metering system of a digital AF reflex
camera is unable to focus due to insufficient
ambient lighting, the camera activates the AF
auxiliary light
ተ built into the flash unit.
This projects a stripe pattern onto the subject
which the camera uses to focus.
With the "AF-BEAM" function, the AF auxiliary
light can be switched on or off.
The range is approx. 6 m... 9 m (with a stan-
dard 1.7/50 mm lens). Parallax error bet-
ween the lens and AF auxiliary light
ተ limits
the close-up range with the AF auxiliary light
to approximately 0.7 m to 1 m.
If the automatic AF auxiliary light
ተ is to be
activated by the camera, the "Single-AF (S-AF)"
autofocus mode must be set on the camera and
the flash unit must indicate flash readiness.
Some camera models support only the came-
ra's internal AF auxiliary light. In this case,
the automatic AF auxiliary light of the flash
unit is not activated (as in the case of com-
pact cameras; see the camera's operating
instructions).
Low-speed zoom lenses can significantly cur-
tail the range of the AF auxiliary light!
Setting procedure
• Press the ቨ button as often as it takes
for the selection menu to appear.
• Press the sensor button on the
touch display.
• Press the sensor buttons on the
touch display and select .
• Press the sensor button on the
touch display.
• Press the or sensor button on the
touch display.
The setting is adopted immediately.
AF BEAM
AF BEAM
Off On
D
OPTION
178
k
OPTION
OPTION
O
q p
POWERPACK
AF BEAM
AF BEAM
O
OFF
ON
