MAINTENANCE
47
8. Now fully tighten the retaining bolts (A) of the
flange bracket (B). Make sure the bolts are
tightened with the correct torque. Refer to
§
11.1.6 .
9. Position hose clamp (A) against O-ring chamber
of the flange bracket (B) and fasten the
retaining bolt. Make sure the bolts are tightened
with the correct torque. Refer to §
11.1.6 .
10. Now fit the other port. For this port proceed in
the same way as described above for the inlet
port.
11. Fill the pump housing with Bredel Genuine
Hose Lubricant. Refer to §
8.4 .
12. Connect the suction and discharge lines (B) and
fit the retaining bolts (A). Tighten the retaining
bolts with the correct torque. Refer to §
11.1.6 .
A
B
A
B
A
B
