32 LDK 4488, LDK 4489 SuperXpander, Xpander User’s Guide (v5.0)
Chapter 4 - Control panel
Menu 2
Menu 3
Menu 4
switch function values description
<page 1 >
top-left ND Filter 1-4 Control of the ND Filter in the camera. If the filter is
not motorized this is an indication.
top-right FX Filter A-D Control of the FX filter in the camera, if available.
bottom-left AutoWhite Off,Window,
On,Fail
Control of the Auto White balace process.
bottom-right Bars On,Off Control of the Color Bar test signal.
switch function values description
< page 1 >
top-left Lamp Off, On Switches the 7-inch viewfinder On Air lamp and
Lens On-Air lamps.
top-right -
bottom-left -
bottom-right -
switch function values description
< page 1 >
top-left -
top-right Iris Ind. F1.4 .. Fclose Indication of the current Iris position in F-stops.
bottom-left Focus Ind. 0..99 Indication of the current focus position in a 0..99
range.
bottom-right Zoom Ind. 0..99 Indication of the current zoom position in a 0..99
range.
< page 2>
top-left -
top-right -
bottom-left Range Extender Off, On Indication of the lens range extender.
bottom-right -
< page 3 >
top-left Lens I/F Analog, Digital Indication of the lens interface currently in use.
top-right link state OK, Not OK indication of the status of the transmission module.
bottom-left -
bottom-right -
