RIGOL Chapter 18 Specifications
18-2 MSO1000Z/DS1000Z User’s Guide
Horizontal
Timebase Scale 5 ns/div to 50 s/div
Max Record
Length
24 Mpts (optional)
Timebase
Accuracy [1]
≤±25 ppm
Clock Drift ≤±5 ppm/year
Max Delay
Range
Negative delay: ≥1/2 screen width
Positive delay: 1 s to 500 s
Timebase Mode YT, XY, Roll
Number of X-Y
1
Waveform
Capture Rate [2]
30,000 wfms/s (dots display)
Zero Offset ±0.5 div*minimum time base scale
Vertical
Bandwidth (-3
dB)
(50 Ω)
MSO1104Z/1104Z-S and DS1104Z Plus/1104Z-S Plus: DC to 100
MHz
MSO1074Z/1074Z-S and DS1074Z Plus/1074Z-S Plus: DC to 70
MHz
DS1054Z: DC to 50 MHz
Single-shot
Bandwidth
(50 Ω)
MSO1104Z/1104Z-S and DS1104Z Plus/1104Z-S Plus: DC to 100
MHz
MSO1074Z/1074Z-S and DS1074Z Plus/1074Z-S Plus: DC to 70
MHz
DS1054Z: DC to 50 MHz
Vertical
Resolution
Analog channe: 8 bit
Digital channel: 1 bit
Vertical Scale
(Probe ratio is
1X)
1 mV/div to 10 V/div
Offset Range
(Probe ratio is
1X)
1 mV/div to 499 mV/div: ±2 V
500 mV/div to 10 V/div: ±100 V
Bandwidth
Limit [1]
20 MHz
Low Frequency
Response
(AC Coupling,
-3dB)
≤5 Hz (on BNC)
Calculated Rise
Time [1]
MSO1104Z/1104Z-S and DS1104Z Plus/1104Z-S Plus: 3.5 ns
MSO1074Z/1074Z-S and DS1074Z Plus/1074Z-S Plus: 5 ns
DS1054Z: 7 ns
