Loewe L 37 Full-HD+ 100 - Manual (Page 30)

- 30
Picture in Picture (PIP)
The concurrent display of two different images is referred to as Picture
in Picture.
➠ The coloured buttons do not work as described below for TV sets
with MHEG-5 software, but they operate as described on page 35
(Digital Teletext).
➠ A concurrent display of two HDTV signals is not possible.
➠ A concurrent display of two coded stations is not possible.
➠ Picture change and station selection is restricted during recording.
➠ PIP mode is restricted to AV-PIP (one TV station and one AV source). If
a satellite tuner is upgraded, PIP mode from digital satellite picture and
analogue picture via cable TV or house antenna is possible additionally.
Your TV set distinguishes between two PIP displays:
Split Screen In this case screen is divided in the middle and the addi-
tonal PIP image is shown on the right side of the screen.
Both images are compressed horizontally and each gets
half of the screen.
Small PIP In this case a small PIP image is inserted in the TV picture.
Start and end picture in picture mode
Show/hide PIP.
A green frame indicates that the station selection acts on
the PIP picture. A white frame means that the operation
refers to the main picture. If the frame is blue, the station
scan is active in the PIP picture.
➠ For TV sets with MHEG-5 Software, you switch from
the green bar/frame to the white by using the PIP
key. The next time you press the PIP key, PIP is
switched off.
PIP as freeze picture
➠ The frame is green,
if not, press the green button.
Red button: Freeze picture in PIP on / off.
Swap contents of PIP and main picture
➠ The frame is green,
if not, press the green button.
Yellow button: Swaps contents of TV picture and PIP picture.
Select the PIP picture
➠ The frame is green,
if not, press the green button.
Select the station as usual.
Select the station for the main picture
➠ The frame is white,
if not, press the green button.
Select the station as usual.
Scan station in the PIP
➠ The frame is green,
if not, press the green button.
Blue button: Start Scan stations.
The frame turns blue,
the stations now change automatically.
Blue button: Stop Scan stations.
The frame is green again.
Picture in Picture
; <&=                            ¬
17.00 - 18.30 Flora & Fauna
1 ARD
17.30 - 20.00 Toskana
