● HP Booklet Maker/Finisher with 2/4 Hole Puncher — Mailbox Mode — CZ999A
● HP Booklet Maker/Finisher with 2/4 Hole Puncher — Stacker Mode — CZ999A
Table 4-1 Two hole punch options by paper size – Long edge tray feed orientation
Paper size Image orientation Two Hole Punch
Left or Top
Two Hole Punch
Left
Two Hole Punch
Right
Two Hole Punch
Top
Two Hole Punch
Bottom
Letter
216 x 279 mm (8.5
x 11 in)
A4
210 x 297 mm (8.3
x 11.7 in)
Portrait
Aa
123
Aa
123
Aa
123
Not supported Not supported
Landscape
Aa
123
Not supported Not supported
Aa
123
Aa
123
Table 4-2 Two hole punch options by paper size – Short edge tray feed orientation
Paper size Image orientation Two Hole Punch
Left or Top
Two Hole Punch
Left
Two Hole Punch
Right
Two Hole Punch
Top
Two Hole Punch
Bottom
Letter
216 x 279 mm (8.5
x 11 in)
A4
210 x 297 mm (8.3
x 11.7 in)
Ledger
279 x 432 mm (11
x 17 in)
A3
279 x 420 mm
(11.7 x 16.5 in)
Legal
216 x 330 mm (8.5
x 13 in)
Oficio
216 x 340 mm (8.5
x 13.4 in)
Portrait
Aa
123
Not supported Not supported
Aa
123
Aa
123
Landscape
Aa
123
Aa
123
Aa
123
Not supported Not supported
3 Hole punch
The following hole punch option tables by paper size for the HP LaserJet Enterprise M806 and HP LaserJet
Enterprise flow MFP M830 applies to these devices:
