Connecting speakers to the speaker terminals
You can connect 7.2 channel speakers to this unit.
Connect each speaker according to the speakers you are using.
z 1 When using a single surround back speaker, connect it to the
SURROUND BACK L terminal.
z 2 The Surround Back speaker terminal can be assigned to the Height/
Ceiling/Dolby Enabled speaker in some speaker systems.
Refer to the section on “Amp Assign” in the menu for instructions on
configuring the settings. ( v p. 188)
SW1 SW2
SR SL FR FL C SBL SBR
z 1
z 2
