Table B-4 10/100 BASE T (Ethernet, TCP/IP)
Table B-5 CP-2 Control Panel
Table B-6 CP-2 Cable Wiring
Pin Signal
1 T2
2 T1
3 R2
4 n/c
5 n/c
6 R1
7 n/c
8 n/c
Pin Signal
1 Gnd
2 Tx+
3 Tx-
4 V+
E-2 end
TA4M pins
CP-2 end
A5F pins
1 1 + 5
2 2
3 3
4 4
