User's manual K&F SEQUENZA 5 incl. accessories
KLING & FREITAG GMBH © 2015 Version 4.1 Page 24 of 88
3. To separate the joints, push
the speaker to the side.
4. Slide the speakers apart.
9. SEQUENZA 5 setup
9.1 Setup Variations
You can choose between the setup variations
• flown setup, SEQUENZA 5 W only
• stacked setup, SEQUENZA 5 W only SEQUENZA 5 B
• flown setup, SEQUENZA 5 W under SEQUENZA 10 N/W
• flown setup, SEQUENZA 5 B only
• stacked setup, SEQUENZA 5 W with SEQUENZA 5 B
• stacked setup, SEQUENZA 5 W with SEQUENZA 5 B, without flying frame
• Setup on a stand, SEQUENZA 5 W only
9.1.1 Setup variations, flown
Warning
If a BGV (government safety organisation) C1 or a D8+ motor is used, the SEQUENZA 5 system
is intrinsically safe and does not require any secondary securing. If the SEQUENZA 5 system
is, however, to be hung on another motor, then secondary securing is necessary. This can be
attached to the 3.5t shackles and must be implemented with zero drop height. Instructions
for the correct use of secondary securing with zero drop height are in the standard VPLT
(Assoc. of Media and Event Technology) SR 2.0 "Preparation & use of electric chain hoists".
Ensure that nobody can step below the suspended systems.
To remove a SEQUENZA 5 B lid, the array must be standing on the ground.
