Remote Analog Programming of Output Voltage and Current Limit

TM-F2OP-C1XN-01

4-5

Table 4-2 Power Supply Settings for Different Programming Sources

Output Voltage
Programming
Source

Output Current Limit Programming Source

0-5 Vdc

0-10 Vdc

0-5 k Resistor

0-10 k Resistor

None (Front
Panel Control)

0-5 Vdc

SW1: set 3 and 4
open.
J2: jumper 1 to 3
and 2 to 3.

SW1: set 3 open.
J2: jumper 1 to 3
and 2 to 3.

SW1: set 2
closed, 3 and 4
open.
J2: jumper 1 to 3
and 2 to 3.

SW1: set 2
closed, 3 open.
J2: jumper 1 to 3
and 2 to 3.

SW1: set 3 open.
J2: jumper 1 to 3.

0-10 Vdc

SW1: set 4 open.
J2: jumper 1 to 3
and 2 to 3.

SW1: default
settings.
J2: jumper 1 to 3
and 2 to 3.

SW1: set 2
closed, 4 open.
J2: jumper 1 to 3
and 2 to 3.

SW1: set 2
closed.
J2: jumper 1 to 3
and 2 to 3.

SW1: default
settings.
J2: jumper 1 to 3.

0-5 k Resistor

SW1: set 1
closed, 3 and 4
open.
J2: jumper 1 to 3
and 2 to 3.

SW1: set 1
closed, 3 open.
J2: jumper 1 to 3
and 2 to 3.

SW1: set 1 and 2
closed, 3 and 4
open.
J2: jumper 1 to 3
and 2 to 3.

SW1: set 1 and 2
closed, 3 open.
J2: jumper 1 to 3
and 2 to 3.

SW1: set 3 open,
1 closed.
J2: jumper 1 to 3.

0-10 k Resistor

SW1: set 1
closed, 4 open.
J2: jumper 1 to 3
and 2 to 3.

SW1: set 1
closed.
J2: jumper 1 to 3
and 2 to 3.

SW1: set 1 and 2
closed, 4 open.
J2: jumper 1 to 3
and 2 to 3.

SW1: set 1 and 2
closed.
J2: jumper 1 to 3
and 2 to 3.

SW1: set 1
closed.
J2: jumper 1 to 3.

None (Front
Panel Control)

SW1: set 4 open.
J2: jumper 2 to 3.

SW1: default
settings.
J2: jumper 2 to 3.

SW1: set 2
closed, 4 open.
J2: jumper 2 to 3.

SW1: set 2
closed.
J2: jumper 2 to 3.

SW1:
default settings.
J2: no jumper.
