User’s Manual—SNAP™ 500 Gen 1 and Gen 2
128
12.21 Electrical Components Assembly – Gen 2
ITEM
PART NO.
DESCRIPTION
QTY
11
631202
BRACKET MCB SUPPORT
1
1
996293
AC ENTRY W/ SWITCH
1
12
991372
6 SCREW, 6-32 X 1/4 PAN PHILLIPS
16
2
581104-1
FAN, HARNESSED, 12V
1
13
991373
8 SCREW, 8-32 X 1/4 PAN PHILLIPS
2
3
581179
SPEAKER, 8 OHM 2W HARNESSED
1
14
991422
4 SCREW, 4-40 X 1/4 PAN HD PHILLIPS
6
4
621004
BRACKET, EXIT FAN MOTOR
1
15
991638
SCREW, 6-32 X 1.250" PHCS
4
5
621134
FAN, HARNESSED 12V HI VEL
1
NS
621007
BRACKET, EXIT FAN CHUTE
6
631001
BRACKET, MCB COOLING FAN
1
NS
581127
HARNESS, MCB TO PANEL FOR STACKER
1
7
631107-500-2/1-0
PCB, MCB 500 2/1 PROGRAMMED
1
NS
591139
POWER SUPPLY, ATX BRICK HARNESSED
1
8
631121
POWER SUPPLY, 24V HARNESSED
1
NS
551130
HARNESS,PRINT HEAD COOLING FAN
2
9
631166A0
PCB, MOTHER BOARD KIT
1
NS
581113
HARNESS, MCB TO MFP
1
10
631201
KIT, FRAME ASSEMBLY, SNAP 500 2/1
1
NS
631133
Harness ,machine ID Programmed
1
NS
581108
PCB, USB INTERCONNECT (USB CARD)
1
