Nozzle Boots, Hose Hook, and Internal Hose Retrievers Hose Hanger and Hose Retriever
Page 16 PT-1949D Gasboy Atlas™ Pump and Dispenser Illustrated Parts Manual · March 2010
Hose Hanger and Hose Retriever
Hose Hanger Option
Item # Part Description Current Part Previous Part Quantity
1 Hook-hose; 9100 003740 - 1
2 Screw - - 2
Internal Hose Retriever - 5/8-inch
Item # Part Description Current Part Previous Part Quantity
1 Stud Metric Clinch Q12887-48 - 1
2 Bracket, Hose Retriever M04752B001 - 1
3 Nut, Metric M8 Serrated M00414B003 - 1
4 Retriever and Cable Assembly N20545-02 - 1
5 Grommet Hose Cable 45 Degrees R18453-01 - 1
6 Nut, Hex 1/4-20 K01941 - 1
7 Clamp, Hose (Inner Half) N18319-03 - 2
8 Nut, Hex Q12068-05 - 1
9 Clamp, Hose, and Cable N18320-21 - 2
10 Ring, Retaining K85573-01 - 1
11 End Cable Block K86055-01 - 1
12 Tie Clamp Q13641-01 - 1
13 Screw Cap OV Flst 1/4-20 K04585 - 1
14 Washer K50411-25 - 1
15 82 Degree Flat Head Machine Screw K78552-21 - 2
16 Flat Head Metric Tamper Resistant M05629B013 - 2
17 Hex Nut 8-32 Unc-28 Stl Zn Pl Q12068-03 - 2
18 Assembly, Nozzle Boot Cover M04641A003 - 1
19 Gasket, Nozzle Boot, Auto M05627B001 - 1
20 Nut, Metric, Hex w/Ext M4 Blue Q12885-05 - 2
21 Spring K89852 - 1
Item # Part Description Current Part Previous Part Quantity
