Item Description Part Number Usage Quantity
1 Lower Air Gap Plate M04299B001 Comm Side-load Non-ATC, All Retail 1
Lower Air Gap Plate M04299B003 Comm Front-load and/or Comm ATC
2 Rain Baffle Plate M06690B001 all 2
3 Upper Air Gap Plate M04461A001 Comm Side-load Non-ATC, All Retail 1
Upper Air Gap Plate M04461A002 Comm Front-load and/or Comm ATC
4 Top Housing Assembly M04483A001 all 1
5 Screw, M8 X 18 WH X HD M00417B009 all 8
6 AC Conduit and Wire M04850A006 Retail 1
AC Conduit and Wire M04850A008 Commercial
7 DC Conduit and Wire M05189A002 Retail and Commercial Pulse-out 1
DC Conduit and Wire M05189A004 All Canada Pulse-out
DC Conduit and Wire M05189A006 RS-485
8 Pivot Bracket M04884B001 all 4
9 Lower Pulser Seal Assembly M03023A002 all Single or Dual 1 or 2
10 Screw, M5 X 10 WH X HD M00417B101 all Single or Dual 4 or 8
11 Upr Pulser Blanking Plate M05083B001 all Single 1
12 Lwr Pulser Blanking Plate M05244B001 all Single 1
13 I.S. Barrier C06766 Commercial Front-load 1
14 Washer, 1.35 X 1.75 X 0.06 068446 Commercial Front-load 1
15 Conduit Nut N23655-01 Commercial Front-load 2
16 Conduit Blanking Plate N23746-01 Comm Front-load OR Comm ATC 2
17 Conduit Seal Washer N23760-03 Commercial Front-load 1
18 Conduit Seal Washer N23760-04 all with Pulse-out or RS-485 2
19 Conduit Seal Washer N23760-06 all 2
20 Conduit Seal Washer N23760-07 Commercial ATC 2
21 Screw, M4 X 8 PN HD M00417B224 all
22 Pulser Drive Gasket M03081B001 all Canada Single or Dual 1 or 2
23 Conduit Seal Gasket N23761-01 all Canada Pulse-out or RS-485 1
24 Conduit Seal Gasket N23761-03 all Canada or Canada Front-load 1 or 2
25 Conduit Seal Gasket N23761-04 Commercial Canada ATC 1
Air Gap - 8800, 9100, 9840, 9852/53 Air Gap Hardware and CD Module Housing
