Connectors on ib893 – IBASE IB893 User Manual
Page 16
INSTALLATIONS
12
IB893 User’s Manual
Connectors on IB893
Connector Locations on IB893 ............................................................ 13
CN5: USB 1/2 Connector .................................................................... 14
CN6: VGA Connector ......................................................................... 14
CN7, CN8: Gigabit LAN RJ45 Connector .......................................... 14
CN9: COM1 RS232/RS422/RS485 Connector ................................... 14
CN1, CN2: SATA Connectors ............................................................. 15
J1: Board Input Power Connector ........................................................ 15
J2/J22: HDD Power Connector (Output Only) .................................... 15
J3: Power LED ..................................................................................... 16
DIMM1: DDR3 SO-DIMM ................................................................. 16
J6, J7, J8: USB3/4/5/6/7/8 Connector .................................................. 16
CN10: LCD Backlight Connector ........................................................ 17
J10: Digital I/O .................................................................................... 17
J11: System Function Connector ......................................................... 18
J24, J25: LVDS Connectors ................................................................ 19
J13: COM3, COM4 Serial Port (DF11 Connector) ............................. 19
J14: Mini PCIE Connector ................................................................... 20
J15: Keyboard & Mouse Connector (DF11 Connector) ...................... 20
J16: SPI Flash Connector (factory use only) ....................................... 20
J17: LPC Connector (factory use only) ............................................... 20
J19: Audio Connector (DF11 Connector) ............................................ 21
J20: COM2/RS232 Serial Port ............................................................. 21
J21: Amplifier Connector .................................................................... 22
