INTRODUCTION
IB893 User’s Manual 1
Introduction
Product Description
The IB893 is a 3.5-inch disk-size SBC featuring the Intel
® Atom™
DC D525 processor with ICH8M chipset. It has one DDR3-800MHz
SO-DIMM memory slot that can fit in up to 4GB of system memory.
VGA graphics support dual 24-bit LVDS interface.
The board has edge connectors for VGA CRT, two RJ45, two LAN/USB
stack connector and a serial port. A total of four RS232 serial ports are
available on board. Expansion is provided with a Mini PCI-e socket.
Other features include two SATA connectors, digital I/O, KB/mouse
headers, watchdog timer, and a +12V DC-in power connector. Board
dimensions are 102mm and 147mm.
