56 Kayenne XL Package — Installation and Service Manual
Section 3 — Control Surfaces
2-ME 35 Control Panel, Flat without Aux
Figure 39. 2-ME 35 Control Panel Dimensions, Flat Installation
Figure 40. 2-ME Control Panel Cutout Dimensions, Flat Installation
Figure 41. 2-ME Support Structure, Flat Installation, w/o Aux Panel
8623266_21
1501.5 mm
59.1 in.
1533.7 mm
60.4 in.
325.4 mm
12.8 in.
10.3 mm
0.4 in.
74.0 mm
2.9 in.
327.5 +/-1 mm
12.9 +/-.04 in.
8623266_22
1311.5 +/-1 mm
51.6 +/-.04 in.
2-ME 25 Panel Cutout
2-ME Panel Flat Install Cutout
(Aux Panel Installed Separately)
2-ME 35 Panel Cutout
1503.5 +/-1 mm
59.2 +/-.04 in.
85 57 28 50
862 2 5420
2x
862 2 5410
2x
8557 2850 855 7 2760
8620 3180
2x
862 0 3180
2x
85 00 64 60
2x
85 00 64 60
2x
85 57 28 50
85 57 2850
855 7 2760
86 20 3180
2x
85 00 6460
2x
8557 2850
8557 2850 8557 2760
8620 3180
2x
850 0 6460
2x
862 0 31 80
2x
850 0 64 60
2x 8620 3180
2x
850 0 6460
2x
8623266_23
